Product Introduction
Plastic Drainage Ditch is an advanced drainage material specially designed for underground water management in civil engineering and infrastructure projects. The product uses modified HDPE resin as the primary raw material and adopts thermal extrusion technology to form a stable three-dimensional drainage structure.
The plastic core is wrapped with permeable geotextile filter fabric, which prevents sediment intrusion while ensuring efficient water discharge. Compared with traditional gravel drainage trenches, Plastic Drainage Ditch offers higher drainage efficiency, lower labor costs and faster construction speed.
This product is especially suitable for retaining wall drainage, tunnel engineering, railway foundations, highways, airport runways and landfill projects. The lightweight and flexible structure allows easy installation even in soft soil areas.
The drainage ditch can effectively reduce hydrostatic pressure inside the soil structure, helping improve engineering stability and extending the service life of the project.
Product Technical Data
| Specification |
Shape |
Weight g/m |
Porosity % |
Hollow Dimension |
Compression Resistance |
| MF7030 |
Rectangle |
350 |
≥82 |
40*10 |
Strong |
| MF1235 |
Rectangle |
600 |
≥82 |
40*20*2 |
Strong |
| MF1550 |
Rectangle |
750 |
≥85 |
40*20*2 |
High |
| MY60 |
Circular |
400 |
≥82 |
Φ25 |
Strong |
| MY100 |
Circular |
1000 |
≥84 |
Φ55 |
High |
| MY150 |
Circular |
1800 |
≥85 |
Φ80 |
Excellent |
Drainage Performance Table
| Test Item |
Value |
| Water Permeability |
Excellent |
| Soil Filtration |
Stable |
| Corrosion Resistance |
Strong |
| Chemical Resistance |
Excellent |
| UV Stability |
Good |
| Flexibility |
High |
| Compression Recovery |
Strong |
| Service Life |
More Than 50 Years |
Why Customers Choose Us
- Professional geosynthetics manufacturer
- Complete export experience
- Custom production available
- Stable product quality
- Strict technical standards
- Fast delivery schedule
- Large production capacity
- Technical guidance support
FAQ
Can Plastic Drainage Ditch be installed in soft soil
Yes. The flexible structure performs well in soft ground and uneven settlement conditions.
What is the advantage compared with stone drainage
It is lighter, easier to install, more efficient and requires less labor.
Is the product environmentally friendly
Yes. HDPE materials are durable and suitable for long-term underground use.
Can the size be customized
Yes. Different widths, diameters and filter fabrics can be customized.
What projects commonly use this product
Roads, tunnels, retaining walls, landfills, sports fields and municipal drainage systems commonly use Plastic Drainage Ditch.
